FANUC Series 30i-MODEL A
External Data Input
Data specification for external tool offset (For milling machine)
Address Data *1
E
A
6
E
A
5
E
A
4
E
A
3
E
A
2
E
A
1
E
A
0
E
D
31
E
D
30
…
E
D
1
E
D
0
0 0 1 a/i
g/w 0 r/l
Sign
0: + Specified by BCD 8-digit code
1: - (0 to +/- 79999999) *1
0 Incremental specification
(Input value is added to present compensation
value)
a/i
1 Absolute specification
(Input value is replaced with present
compensation value)
0 Specification of tool wear offset value
g/w
1 Specification of tool geometry offset value
0 Specification of tool length compensation value
r/l
1 Specification of cutter compensation value
Notice 1: If the parameter EED (No.6301#3) is set to “0”, the offset value is specified by using
signals ED0 to ED14, the sign is decided by the signal ED15.
The range of data is available to specify the data from 0 to +/- 7999.
Offset value
