FANUC Series 30i-MODEL A
External Data Input
Signals
Address signals for external data input EA0 to EA6 <Gn002.6 – Gn002.0>
[Classification] Input signal
[Function] These signals indicate the type of the entered data.
Data signals for external data input ED0 to ED31 <Gn211, Gn210,Gn000, Gn001>
[Classification] Input signal
[Function] These signals indicate the entered data.
The use of the 32 code signals (16 code signals) varies with the data type.
Read signal for external data input ESTB <Gn002.7>
[Classification] Input signal
[Function] The signal reports that the address and data are set in external data input.
When the signal is set to “1”, the control unit reads the address and data for
external data input.
Read completion signal for external data input EREND <Fn060.0>
[Classification] Output signal
[Function] This signal reports that the control unit has finished reading the entered data.
Search completion signal for external data input ESEND <Fn060.1>
[Classification] Output signal
[Function] This signal report that program number search, specified by external data
input, has been completed.
[Output condition] This signal is set to “1” when:
- The program number search specified by external data input is completed.
The signal is set to “0” when:
- An automatic operation is started.
- A reset occurs.
Signal address
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
Gn000 ED7 ED6 ED5 ED4 ED3 ED2 ED1 ED0
Gn001 ED15 ED14 ED13 ED12 ED11 ED10 ED9 ED8
Gn002 ESTB EA6 EA5 EA4 EA3 EA2 EA1 EA0
Gn210 ED23 ED22 ED21 ED20 ED19 ED18 ED17 ED16
Gn211 ED31 ED30 ED29 ED28 ED27 ED26 ED25 ED24
Fn060 ESEND EREND
