FANUC Series 16i/18i-MA
FANUC Series 16i/18i-TA
128 Straightness compensation points
A-76424EN
2001.03.26
Egashira
2/10
1. Outline
1. Outline1. Outline
1. Outline
In straightness compensation, compensation data is set as the compensation amounts at the
individual compensation points, in the same way as in stored pitch error compensation. This
enables fine compensation.
Up to six combinations of travel and compensation axes can be used in the straightness
compensation function.
!
Up to 128 compensation points can be set per axis.
!
The settings(a, b, , , y, and z) at the individual compensation points can be from -128 to
+127
!
The method of setting data and the compensation timing are the save as those of pitch
error compensation.
!
The number of straightness compensation points is the same as that of stored pitch error
compensation points on a travel axis.
012345
abcde..
60 61 62 63 64 65
.. .. .. .. .. ..
125122 123 124 126 127
.. .. .. x y z
