FANUC Series 16i/18i-MA
FANUC Series 16i/18i-TA
128 Straightness compensation points
A-76424EN
2001.03.26
Egashira
8/10
13381
Straightness compensation point number of most negative side of move axis 1
13382
Straightness compensation point number of most negative side of move axis 2
13383
Straightness compensation point number of most negative side of move axis 3
13384
Straightness compensation point number of most negative side of move axis 4
13385
Straightness compensation point number of most negative side of move axis 5
13386
Straightness compensation point number of most negative side of move axis 6
[Data type] Word
[Valid data range] 6000-6767
Specify the straightness compensation point number located
at the most negative position for each move axis.
When the value set in this parameter is out of the data range,
an alarm is issued, and compensation cannot be performed.
13391
Straightness compensation multiplier of move axis 1
13392
Straightness compensation multiplier of move axis 2
13393
Straightness compensation multiplier of move axis 3
13394
Straightness compensation multiplier of move axis 4
13395
Straightness compensation multiplier of move axis 5
13396
Straightness compensation multiplier of move axis 6
[Data type] Byte
[Valid data range] 0-100
Specify a straightness compensation multiplier for each axis.
When the straightness compensation multiplier is set to 1, the
unit of compensation data is the same as the detection unit.
When the multiplier is set to 0, straightness compensation is
not applied.
