FANUC Series 16i/18i-MA
FANUC Series 16i/18i-TA
128 Straightness compensation points
A-76424EN
2001.03.26
Egashira
7/10
3.
3. 3.
3. Parameter
ParameterParameter
Parameters
ss
s
5711 Axis number of straightness compensation move axis 1
5712 Axis number of straightness compensation move axis 2
5713 Axis number of straightness compensation move axis 3
5714 Axis number of straightness compensation move axis 4
5715 Axis number of straightness compensation move axis 5
5716 Axis number of straightness compensation move axis 6
[Data type] Byte
[Valid data range] From 1 through the number of controlled axes
Set the axis number of a straightness compensation move axis
5721
Axis number of compensation axis 1 for straightness compensation move axis 1
5722
Axis number of compensation axis 2 for straightness compensation move axis 2
5723
Axis number of compensation axis 3 for straightness compensation move axis 3
5724
Axis number of compensation axis 4 for straightness compensation move axis 4
5725
Axis number of compensation axis 5 for straightness compensation move axis 5
5726
Axis number of compensation axis 6 for straightness compensation move axis 6
[Data type] Byte
[Valid data range] From 1 through the number of controlled axes
Set the axis number of compensation axis
