FANUC Series 16i/18i-MA
FANUC Series 16i/18i-TA
128 Straightness compensation points
A-76424EN
2001.03.26
Egashira
6/10
2.3.3 A compensation axis can be set as a travel axis.
Example of Setting Parameters 3
Setting of the travel axis Setting of the compensation axis
Parameter
number
Setting Parameter
number
Setting
Effective magnification
5711 1 5721 2 Value set for parameter No.13391
5712 2 5722 3 Value set for parameter No.13392
5713 3 5723 4 Value set for parameter No.13393
5714 4 5724 5 Value set for parameter No.13394
As described above, a compensation axis can be set as a travel axis.
If a compensation axis is set as such, the amount of travel due to compensation on
the travel axis is not subject to compensation.
2.3.4 A single compensation axis can have two or more travel axes.
Example of Setting Parameters 4
Setting of the travel axis Setting of the compensation axis
Parameter
number
Setting Parameter
number
Setting
Effective magnification
5711 1 5721 5 Value set for parameter No.13391
5712 2 5722 5 Value set for parameter No.13392
5713 3 5723 5 Value set for parameter No.13393
5714 4 5724 5 Value set for parameter No.13394
As described above, a single compensation axis can have two or more travel axes.
