FANUC Series 16i/18i-MA
FANUC Series 16i/18i-TA
128 Straightness compensation points
A-76424EN
2001.03.26
Egashira
5/10
2.3 Examples
2.3 Examples2.3 Examples
2.3 Examples
The flowing explains the method of setting parameters for the travel and compensation axes,
as well as effective magnification. The parameters for travel and compensation axes can be
set as follows.
2.3.1 A single compensation axis can be set for a single travel axis.
Example of Setting Parameters 1
Setting of the travel axis Setting of the compensation axis
Parameter
number
Setting Parameter
number
Setting
Effective magnification
5711 1 5721 2 Value set for parameter No.13391
5712 3 5722 4 Value set for parameter No.13392
5713 5 5723 6 Value set for parameter No.13393
5714 7 5724 8 Value set for parameter No.13394
When the parameters are set as shown above, by moving the machine along the first
axis, compensation is applied to the second axis. Similarly, by moving the machine
along the third and fifth axes, compensation is applied to the fourth and sixth axes,
respectively.
The numbers of the parameters for the magnifications that are made effective for the
individual travel and compensation axis combinations are as given in the table
above.
2.3.2 Two or more compensation axes can be set for a single travel axis.
Example of Setting Parameters 2
Setting of the travel axis Setting of the compensation axis
Parameter
number
Setting Parameter
number
Setting
Effective magnification
5711 1 5721 2 Value set for parameter No.13391
5712 1 5722 3 Value set for parameter No.13392
5713 1 5723 4 Value set for parameter No.13393
5714 1 5724 5 Value set for parameter No.13394
As described above, two or more compensation axes can be set for a single travel
axis.
