Revision of Spindle Software 9D50 Edition M, 9D53 Edition D, 9D70 Edition C Additional Manual Page 1

Additional Manual
1/8
Design.
Date Ed.
1
04.11.30
S
HEET
DRAW. No.
C
U
S
T.
TITLE
M. Niwa
Revision of αi series Spindle software
9D50 edition M, 9D53 edition D
and 9D70 edition C
A-63448E-108
FANUC LTD
01
Revision of Spindle software 9D50 edition M, 9D53 edition D, 9D70 edition C
1. General
αi series Spindle software 9D50, 9D53 and 9D70 series was revised as follows.
2. ROM series, edition and applied PCB
ROM
drawing No.
ROM
edition
SPM specification Applied PCB Notes
A06B-6111-H550
9D50
edition M
(13)
A06B-6111-Hxxx#H550
A06B-6112-Hxxx#H550
A06B-6121-Hxxx#H550
A06B-6122-Hxxx#H550
A20B-2100-0800
A20B-2100-0801
16i/18i/21i/
15i/0i,
for induction
spindle motor
A06B-6134-Hxxx#A
A20B-2101-0012+A20B-2902-0670
A20B-2101-0013+A20B-2902-0670
0i,
for SVPM
(induction
spindle motor)
A06B-6111-H553
9D53
edition D
(04)
A06B-6111-Hxxx#H553
A06B-6112-Hxxx#H553
A06B-6121-Hxxx#H553
A06B-6122-Hxxx#H553
A20B-2100-0800
A20B-2100-0801
16i/18i/21i/
15i/0i,
for synchronous
spindle motor
A06B-6111-H570
9D70
edition C
(03)
A06B-6111-Hxxx#H570
A06B-6112-Hxxx#H570
A06B-6121-Hxxx#H570
A06B-6122-Hxxx#H570
A20B-2100-0800
A20B-2100-0801
30i/31i/32i,
for induction
& synchronous
spindle motor
3. Contents of modification
Contents of modifications 9D50/M 9D53/D 9D70/C
1Dual position feedback function for servo mode (rigid tapping / spindle
positioning) is added.
2Communication alarm occurs when CNC power is turned on in FS15i-MB
3Torque tandem function is added.
(See “Spindle Amplifier αi series Torque Tandem Control : A-53866-0450 ”
for details.)
4Unexpected disturbance torque detection function for synchronous
spindle motor is added.
5Disconnection detection disable function (Input signal : DSCN) for
synchronous spindle motor is added.
: revised item
