4. Dual position feedback function for servo mode [9D50/M, 9D53/D, 9D70/C]
4.1. General
Dual position feedback function for servo mode (rigid tapping / spindle positioning) is added.
See “FANUC AC SPINDLE MOTOR αi series PARAMETER MANUAL : B-65280EN” for detailed
specification of dual position feedback function.
Remark
* Dual position feedback function is unavailable in SUB spindle of Spindle Switching Control.
4.2. Related parameters
4.2.1. Remark
Parameters listed in table below are the same with parameters related to dual position feedback for
Cs contouring control.
parameter No.
15i 16i 30i
Description
3014#7 4014#7 4014#7
Function bit of dual position feedback
3171
3173
4171
4173
4171
4173
Denominator of conversion coefficient
3172
3174
4172
4174
4172
4174
Numerator of conversion coefficient
4.2.2. Details of related parameters
15i 16i 30i
3520 4520 4520
Primary delay time constant in dual position feedback [for servo mode]
Unit of data 1msec
Valid data range 0 to 32767
Standard setting 0
Sets primary delay time constant in dual position feedback for servo
mode (rigid tapping / spindle positioning).
If hunting occurs during acceleration / deceleration, set a larger
value.
Setting “0” provides control equivalent to closed loop.
Setting “32767” provides control equivalent to semi-closed loop.
