Revision of Spindle Software 9D50 Edition M, 9D53 Edition D, 9D70 Edition C Additional Manual Page 6

Additional Manual
6/8
Design.
Date Ed.
1
04.11.30
S
HEET
DRAW. No.
C
U
S
T.
TITLE
M. Niwa
Revision of αi series Spindle software
9D50 edition M, 9D53 edition D
and 9D70 edition C
A-63448E-108
FANUC LTD
01
available.
0 : Unavailable
1 : Available
This parameter is specified automatically by the software option.
15i 16i 30i
3248 4248 4248
Torque constant for spindle load monitoring
Unit of data : -
Valid data range : 0 to 32767
Standard setting value : 0
Specify the torque constant “
Kt
“ for calculating the spindle load
torque, using the following calculation.
889.4
max
×
+
=
JlJm
T
Kt
T
max : Motor maximum output torque [Nm] (Use output torque at
maximum current)
Jm
: Motor rotor inertia [kgm
2
]
Jl
: Spindle inertia [kgm
2
] (in terms of motor axis inertia)
15i 16i 30i
3249 4249 4249
Observer gain 1 for spindle load torque monitoring
3250 4250 4250
Observer gain 2 for spindle load torque monitoring
Unit of data : -
Valid data range : 0 to 32767
Standard setting value : 500
Specify the gain for the spindle load torque estimation observer.
Usually, please set “500”.
15i 16i 30i
3341 4341 4341
Unexpected disturbance torque detection level
Unit of data : 0.01%
Valid data range : 0 to 10000
Standard setting value : 0
Specify the output level for the spindle unexpected disturbance
torque detection signal, using a percentage to the motor maximum
output torque. If this parameter is set to “0”, no spindle unexpected
disturbance torque detection signal is output.
