3 Parameter
#7 #6 #5 #4 #3 #2 #1 #0
03713 MSP
[Data type] Bit
MSP Spindle control M,S,P format is
0: unavailable.
1: available.
Note 1 This function is included in multi-spindle control. Multi-spindle control is an optional
function. And in order to use Spindle control M, S, P format, the following parameter is
necessary.
- Spindle select function by address P (MPP : 3703#3)
- Multi-spindle control TYPE-C (MSC : 3713#3)
Note 2 When this parameter is changed, POWER MUST BE OFF alarm occurs.
13550 M value for M03 with 1st spindle
13551 M value for M03 with 2nd spindle
13552 M Value for M03 with 3rd spindle
13553 M value for M03 with 4th spindle
[Data type] 2 word type
[Valid data range] 0, 1 to 99999999
Set the value of the M code to output to PMC by the following command.
M03 (Sxxxxx) Pxx ;
13554 M value for M04 with 1st spindle
13555 M value for M04 with 2nd spindle
13556 M Value for M04 with 3rd spindle
13557 M value for M03 with 4th spindle
[Data type] 2 word type
[Valid data range] 0, 1 to 99999999
Set the value of the M code to output to PMC by the following command.
M04 (Sxxxxx) Pxx ;
A-79124E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Apr.28.’03 Desig. Apprv.
FANUC Series 16i/18i/21i – TB
Spindle control M, S, P format specifications
6/12
