  2. FS 16i/18i/21i-TB, Spindle Control M, S, P format, Specification

FS 16i/18i/21i-TB, Spindle Control M, S, P format, Specification Additional Manual Page 7

Additional Manual
13558 M value for M05 with 1st spindle
13559 M value for M05 with 2nd spindle
13560 M Value for M05 with 3rd spindle
13561 M value for M05 with 4th spindle
[Data type] 2 word type
[Valid data range] 0, 1 to 99999999
Set the value of the M code to output to PMC by the following command.
M05 (Sxxxxx) Pxx ;
13562 M value for M19 with 1st spindle
13563 M value for M19 with 2nd spindle
13564 M Value for M19 with 3rd spindle
13565 M value for M19 with 4th spindle
[Data type] 2 word type
[Valid data range] 0, 1 to 99999999
Set the value of the M code to output to PMC by the following command.
M19 (Sxxxxx) Pxx ;
Note 1 Parameter 13550 - 13565 are parameters for Spindle control M, S, P format
It is necessary to set MSP(3713#5)=1.
Note 2 When using Multiple command of auxiliary function (M code 3 pair) (=M3B 3404#7),
please set equal to or less than 65535 value to these parameters.
( Reason : The 2nd/3rd M code of Multiple command of auxiliary function can handle
only equal to or less than 65535 value.)
Note 3 When this parameter is changed, POWER MUST BE OFF alarm occurs.
A-79124E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Apr.28.’03 Desig. Apprv.
FANUC Series 16i/18i/21i – TB
Spindle control M, S, P format specifications
7/12
