4 Signals
The output signal address that the M code after changed is the same as the case of
usual auxiliary function. < F010 - F013 >
When using Multiple command of auxiliary function (M code 3 pair) (=M3B 3404#7),
the each M codes after changed is output as follows.
- 1st M code :
< F010 - F013 >
- 2nd M code :
< F014, F015 >
- 3rd M code :
< F016, F017 >
Please refer to "FANUC Series 16i/18i/21i- MODEL B CONNECTION MANUAL
(FUNCTION) - 8. AUXILIARY FUNCTION"
The selected spindle can be confirmed by the following signal <F160, F161>.
Address P signals
MSP00 to MSP15
<F160-F161>
[Classification] Output signal
[Function] These signals report last commanded address P value in
“S_P_” or “M_P_” (Word data)
[Output condition] These signals are set when “S_ P_” or “M_ P_” is
commanded in multi-spindle control (Parameter 3703#3=1).
When “S_ P_” or “M_ P_” has not been commanded after
power-on, the value of parameter 3775 is set.
Signal addresses
#7 #6 #5 #4 #3 #2 #1 #0
F0160 MSP07 MSP06 MSP05 MSP04 MSP03 MSP02 MSP01 MSP00
#7 #6 #5 #4 #3 #2 #1 #0
F0161 MSP15 MSP14 MSP13 MSP12 MSP11 MSP10 MSP09 MSP08
Please refer to "Additional function of spindle select by address P (Multi-spindle
control)".
A-79124E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Apr.28.’03 Desig. Apprv.
FANUC Series 16i/18i/21i – TB
Spindle control M, S, P format specifications
9/12
