FS 16i/18i/21i-TB, Spindle Control M, S, P format, Specification Additional Manual Page 8

Additional Manual
#7 #6 #5 #4 #3 #2 #1 #0
03703 MPP
[Data type] Bit
MPP In multi-spindle control, spindle select function by address P is
0: not available.
1: available.
Note 1 When this function is used, set the parameters No.3781-No.3784.
03781 P number for 1st spindle
03782 P number for 2nd spindle
03783 P number for 3rd spindle
03784 P number for 4th spindle
[Data type] Word type
[Valid data range] 0, 1 to 32767
These parameters set P numbers for each spindle in multi-spindle control.
Example When Prm.3781 on path-1 = 11, Prm.3781 on path-2 = 21 and S1000 P21 is
executed on path-1, the first spindle on path-2 rotates at 1000 min
-1
.
As for the parameter MPP (3703#3) and No.3781 to 3784, refer to following specifications.
- FANUC Series 16i/18i/21i- TA/TB Spindle select by address P (Multi-spindle control) (A-77777E)
#7 #6 #5 #4 #3 #2 #1 #0
03713 MSC
[Data type] Bit
MSC Multi-spindle control TYPE-C is
0: unavailable.
1: available.
As for the parameter MPP (3713#3), refer to following specifications.
- FANUC Series 16i/18i/21i- MB/TB multi-spindle control type C specifications (A-79114E)
A-79124E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Apr.28.’03 Desig. Apprv.
FANUC Series 16i/18i/21i – TB
Spindle control M, S, P format specifications
8/12
