FS 16i/18i-TB Compound Machining Function Additional Manual Page 116

Additional Manual
A-78656E/01 FANUC Series 16i/18i-TB Compound Machining Function
115/127
Nov.14.2001 Edition 1
8.1
Outline
The compound machining function is realized with the system
software only for the compound machining function. Therefore, the
loading to F-ROM, the parameter setting procedure, and so on are
different from the standard system software.
This chapter will explain the procedure from the all clear of the
memory to the automatic setting of the spindle parameter.
8.1.1
Memory
The compound machining function needs the following memories.
F-ROM more than 32MB
DRAM more than 32MB
SRAM more than 1MB
8.1.2
System software
The compound machining function needs the following systems.
B1H3 ( for turning side ) B0H3 (for milling side) : for FS16i
BEH3 ( for turning side ) BDH3 (for milling side) : for FS18i
These series can run on both LCD-mounted type and Stand Alone
Type.
