FS 16i/18i-TB Compound Machining Function Additional Manual Page 16

Additional Manual
A-78656E/01 FANUC Series 16i/18i-TB Compound Machining Function
15/127
Nov.14.2001 Edition 1
2.2.7
Reference point
If a reference point of an axis is established in one command mode,
that of the same axis in the other mode will be established
automatically.
The established reference points are physically the same on the
machine for both command modes.
When a reference point
is established
in turning mode.
When a reference point
is established
in milling mode.
NOTE
•
Automatic coordinate system setting at the manual
reference point return is to be done for both
command modes at the same time and each
coordinate system to be established separately.
•
The established reference points are never to be lost
on changing command modes.
•
If the reference point is lost in one command mode
caused by a servo alarm or so, the other mode’s is to
be lost, too.
Turning mode
Ref. point not established
Milling mode
Ref. point not established
Turning mode
Ref. point to be established
Manual reference
point return
Milling mode
Ref. point to be established
Automatically
Low-speed reference
point return
Turning mode
Ref. point not established
Milling mode
Ref. point not established
Turning mode
Ref. point to be established
Milling mode
Ref. point to be established
Automatically
