FS 16i/18i-TB Compound Machining Function Additional Manual Page 15

Additional Manual
FANUC Series 16i/18i-TB Compound Machining Function A-78656E/01
Nov.14.2001 Edition 1
14/127
2.2.6
Coordinate system
Coordinate system for each command mode is independent, too.
When axes are moved by motion commands, coordinate positions for
both command modes are to be updated.
With changing command modes, coordinate systems are also to be
changed.
Unlike motion commands, coordinate system setting commands such
as G50(G92) in one command mode do not affect the other’s.
Move command
in turning mode
Coordinate system setting
command in turning mode
Turning mode
Absolute Relative Machine
X___ X___ X___
Z___ Z___ Z___
Milling mode
Absolute Relative Machine
X___ X___ X___
Y___ Y___ Y___
Z___ Z___ Z___
Milling mode
Absolute Relative Machine
X___ X___ X___
Y___ Y___ Y___
Z___ Z___ Z___
Turning mode
Absolute Relative Machine
X___ X___ X___
Z___ Z___ Z___
Positions to be updated Positions not to be updated
Coordinate positions only for turning command mode to be updated
