FS 16i-160i-LA Two Laser oscillators control function Additional Manual Page 7

Additional Manual
2-6 Mirror image
When the two oscillators control function is effective, the mirror image function can be
used on master axis or slave axis respectively during synchronously driving mode of the
twin table control function.
2-7 Tracing control of Z axis and W axis
The similar control function as tracing control can be realized by using "Tracing control
function by the manual handle interruption".
The movement by tracing control is added in the work coordinate system by work
coordinate system preset function (G92.1Z0W0) when the tracing control function turns
off. Afterwards, absolute instruction mode can be effective to the Z and W axis.
Please refer to specifications (A-78541E) of "Tracing control function by the manual
handle interruption" for details.
3．Parameters
Related parameters are shown below.
#7 #6 #5 #4 #3 #2 #1 #0
15000 AGA
AGA Assist gas is :
０：enabled.
１：disabled.
#7 #6 #5 #4 #3 #2 #1 #0
15001 LHC
LHC The oscillator is controlled by :
０：G-code.
１：external signals.
Please refer to "Twin table function specifications A-60920E" for the parameter which
relates to the twin table control function
01 01.10.19 Tokito Newly designed.
Drawing No.
A - 78540E
Tilte
FS-16i/160i-LA
Two laser oscillators control functions
-- Specifications --
Edit Date Design Recog. Contents Page 7 / 9
