５．Limitations
1. Synchronous control signals for slave axes of synchronous control cannot be changed
in the AICC mode.
2. When cutter compensation C function is used during the slave table is singly driven
by X, V, and W axes, it is necessary to select X-V plane (G17 X0 V0).
Example：Ｇ17 X0 V0 ;
M05 ; （The signals are changed to the slave axes single drive mode.）
G42 Ｇ01 X50. Y60. D1 ;
：
3. Reverse movement should be operated in the same synchronous mode as forward
movement . Please operate the synchronous control signals by PMC so that the
synchronous mode becomes the same.
4. The program re-start function for laser specification and the near point search
function cannot be used.
For the program re-start function for machining system, the program that includes
changing synchronous mode cannot be re-started.
5. The processing restart function cannot be used during the W-axis slave single driving.
6．Note
Please refer to the specification of twin table control.
01 01.10.19 Tokito Newly designed.
Drawing No.
A - 78540E
Tilte
FS-16i/160i-LA
Two laser oscillators control functions
-- Specifications --
Edit Date Design Recog. Contents Page 9 / 9
