FANUC Open CNC Setup procedure for Windows 95/NT4.0 Additional Manual Page 4

Additional Manual
Edit Date Desig. Description
Title
Draw. No.
FANUC Open CNC
Setup procedure for Windows95/NT4.0
A-63707E
FANUC LTD
Sheet
4/12
Cust.
01 980908 Kayano New registration
04
000217
Kayano
A
ll pages modified
4. In case that the PC module is for the T type of 160/180/210, 160i/180i/210i (including the
multi-path), or for 150, 150i, open [Control Panel] after the restart of Windows 95.
Double-click the [MDI] icon and select the proper item on the [MDI Keyboard type:]
according to the system to be connected, then click [OK] button. Close [Control Panel].
C. Display driver installation
C. Display driver installationC. Display driver installation
C. Display driver installation
1. Right-click on the desktop field of Windows 95 to open the menu. Select [Properties] from
that menu to invoke [Display Properties] window. Click [Settings] tab.
2. In case of the PC module which has Pentium or MMX-Pentium Card PC, do the following
steps, from 3 to 6. Otherwise, select "256 Colors" on the [Color palette] field and click
[OK] button, then go to step 7.
3. Click [Advanced Properties] button and click [Change] button at the [Adapter] tab.
4. Click [Have Disk] button. Insert 1st "Open CNC Drivers Disk (A02B-0207-K791#ZZ07-1
or A02B-0207-K792#ZZ07-1)" into floppy drive and enter “a:\disp\win95
a:\disp\win95a:\disp\win95
a:\disp\win95” onto the [Copy
Manufacturer's files from:] field. Then click [OK] button.
5. Confirm that "NeoMagic Magic Graph 128ZV" is displayed in case of Pentium version, or
“Trident 9320, Linear Accelerated for PCI (v4.02.12)” is displayed in case of MMX-
Pentium version on [Models:] and click [OK] button. And then click [Close] button at the
next window.
6. Confirm that "256 Colors" is selected on the [Color palette] field, and click [OK] button.
7. When [System Settings Change] dialog box appears, remove the floppy disk from the
floppy drive and click [Yes] button. Windows 95 will restart.
In case that Touch panel is configured with the Device, continue the following procedures "D.
Touch panel driver installation" and "E. Calibration of touch panel". Otherwise, the
installation of Open CNC drivers is finished.
D. Touch panel driver installation
D. Touch panel driver installationD. Touch panel driver installation
D. Touch panel driver installation
1. Open [Control Panel] and double-click the [Add New Hardware] icon to invoke [Add New
Hardware Wizard] window. Click [Next>] button.
2. When the question, "Do you want Windows to search for your new hardware?" appears on
the screen, select [No] and click [Next>] button.
3. Select [Mouse] on the [Hardware types] field, then click [Next>] button.
4. Click [Have Disk] button on [Manufacturers] – [Models] window.
5. Insert 1st "Open CNC drivers disk" into the floppy drive and enter “a:\touch\win95
a:\touch\win95a:\touch\win95
a:\touch\win95” onto
the [Copy Manufacturer's files from] field. Then click [OK] button.
6. Confirm that "Fujitsu Takamisawa Component Fidmouse" is displayed on [Models] and
click [Next>] button. And then click [Finish] button at the next window.
