FS16i/18i –MA/MB/TA/TB, 18i–MB5, 21i–MB/TB
Time constant for acceleration/deceleration during
High-speed and High-precision function modes
Specifications
June.7.2004
11/14
Sheet
T.Mochida E.Genma
- Acceleration/Deceleration for rapid traverse during High-speed and High-precision function
modes
1620
Time constant used for linear acceleration/deceleration or bell–shaped
acceleration/deceleration (T1) in rapid traverse for each axis
1773
Time constant used for linear acceleration/deceleration or bell–shaped
acceleration/deceleration (T1) in rapid traverse for each axis
during AICC, AI-NANO-CC, HPCC, AI-HPCC, AI-NANO-HPCC and
5-axis machining function modes
[Data type] Word axis
[Unit of data] msec
[Valid data range]
Data range
Constant acceleration
type
Constant acceleration
time type
Function
LRP(No.1401#1)=0
or
LRP(No.1401#1)=1 &
PRT(No.1603#4)=0
LRP(No.1401#1)=1 &
PRT(No.1603#4)=1
Normal operation
APC
0 ~ 4000
0 ~ 4096 (total setting
time of each axis)
Data range
Acc/Dec before
interpolation
Acc/Dec after
interpolation
Function
AIR(No.7054#1)=0
or
AIR(No.7054#1)=1 &
LRP(No.1401#1)=1
AIR(No.7054#1)=1 &
LRP(No.1401#1)=0
AI-APC
AICC
AI-NANO-CC
0 ~ 4000
Function Data range
HPCC
AI-HPCC,
AI-NANO-HPCC,
5-axis machining function modes
0 ~ 4000
No.1620: Time constant used for linear acceleration/deceleration or bell–shaped
acceleration/deceleration (T1) in rapid traverse for each axis is set.
No.1773: Time constant used for linear acceleration/deceleration or bell–shaped
acceleration/deceleration (T1) in rapid traverse for each axis during AICC,
AI-NANO-CC, HPCC, AI-HPCC, AI-NANO-HPCC and 5-axis machining
function modes is set.
When 0 is set in this parameter, parameter No.1620 becomes effective.
