FS16i/18i Additional Manual Page 4

Additional Manual
A-78714EN
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FS16i/18i –MA/MB/TA/TB, 18i–MB5, 21i–MB/TB
Time constant for acceleration/deceleration during
High-speed and High-precision function modes
Specifications
June.7.2004
4/14
Sheet
T.Mochida E.Genma
Parameter
- Acceleration/Deceleration after interpolation for cutting feed during High-speed and High-
precision function modes
1768
Time constant used for linear acceleration/deceleration or bell–shaped
acceleration/deceleration after interpolation for cutting feed
during High-speed and High-precision function modes
[Data type] Word
[Unit of data] msec
[Valid data range]
Function Data range
APC
AI-APC
0, 8 ~ 512
AICC 0, 8 ~ 256
AI-NANO-CC 0, 8 ~ 512 (*1)
Data range
Parameter No.8480#4,#5,#6
Function
#4=0
#5=1
#6=0
#4=1
#5=0
#6=0
#4=0
#5=0
#6=0
#4=1
#5=1
#6=1
HPCC 0, 8 ~ 256 0, 8 ~ 128 0, 8 ~ 64 -
AI-HPCC,
AI-NANO-HPCC,
5-axis machining function
-
-
0, 8 ~ 256
(*1)
0, 8 ~ 128
(*1)
(*1) : When the system which is earlier than the edition described below is used, the
setting range becomes 1/4 of the above table.
i-Model A :
B0F4-12 (FS16i-MA)
BDF4-12 (FS18i-MA)
B1F4-07 (FS16i-TA)
BEF4-07 (FS18i-TA)
i-Model B
B0H1-17 (FS16i-MB)
BDH1-17 (FS18i-MB)
BDH5-07 (FS18i-MB5)
DDHA-02 (FS21i-MB)
B1H1-17 (FS16i-TB)
BEH1-17 (FS18i-TB)
DEHA-03 (FS21i-TB)
Time constant used for linear acceleration/deceleration or bell–shaped acceleration/
deceleration after interpolation for cutting feed during High-speed and High-precision
function modes is set. The acceleration/deceleration type is selected by the
parameter LS2(No.1602#6), BS2 (No.1602#3).
When the value over the above range is set, the value is clamped by the maximum
value according to the data range of the above table.
