FS16i/18i Additional Manual Page 2

Additional Manual
A-78714EN
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FS16i/18i –MA/MB/TA/TB, 18i–MB5, 21i–MB/TB
Time constant for acceleration/deceleration during
High-speed and High-precision function modes
Specifications
June.7.2004
2/14
Sheet
T.Mochida E.Genma
Overview
Time constant for acceleration/deceleration during the High-speed and High-precision
function modes is explained.
Note that about AI contour control (AICC) it is explained in case servo FAD function is
not used (Parameter MI1, MI0 (No.7050#6, #5) = 0, 1), and about High precision
contour control (HPCC) it is explained in case rapid traverse is executed with RISC
board in the same way as normal (Parameter SG0(No.8403#7)=1,
STG(No.8404#0)=1 and HG0(No.8404#1)=1).
[Acceleration/Deceleration for cutting feed]
Parameter No. for cutting feed
Acc/Dec after
interpolation
Acc/Dec before
interpolation
Function
Linear Bell Linear Bell
Normal operation 1622 1631
Advanced preview control (APC)
AI advanced preview
control (AI-APC)
AI contour control (AICC)
AI NANO contour control
(AI-NANO-CC)
1771
T1:1771
T2:1772
High precision contour
control (HPCC)
8401
T1:8401
T2:8416
AI high precision contour
control (AI-HPCC)
AI NANO high precision
contour control
(AI-NANO-HPCC)
5- axis machining function
1768
(Common to all axes)
or
1769
(For each axis)
8401
(Common to all axes)
or
19510
(For each axis)
T1:8401
(Common to all axes)
or
19510
(For each axis)
T2:8416
[Acceleration/Deceleration for rapid traverse(G00)]
Parameter No. for rapid traverse(G00)
Function
Linear Acc/Dec Bell shaped Acc/Dec
Normal operation
Advanced preview control (APC)
AI advanced preview
control (AI-APC)
1620
T1:1620
T2:1621
AI contour control (AICC)
AI NANO contour control
(AI-NANO-CC)
High precision contour
control (HPCC)
AI high precision contour
control (AI-HPCC),
AI NANO high precision
contour control
(AI-NANO-HPCC),
5-axis machining function
1620 or 1773
T1:1620 or 1773
T2:1621 or 1774
Previous page
Next page

Contents Summary of FS16i/18i Additional Manual
