FS16i/18i Additional Manual Page 12

Additional Manual
A-78714EN
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FS16i/18i –MA/MB/TA/TB, 18i–MB5, 21i–MB/TB
Time constant for acceleration/deceleration during
High-speed and High-precision function modes
Specifications
June.7.2004
12/14
Sheet
T.Mochida E.Genma
NOTE
1. Parameter No.1773 is not effective in the normal operation, APC and
AI-APC. Parameter No.1620 is effective in these modes.
2. In the following case, Acc/Dec before interpolation is selected and
positioning is performed with linear interpolation:
AI-APC, AICC,AI-NANO-CC:
AIR(No.7054#1)=0, or
LRP(No.1401#1)=1 & AIR(No.7054#1)=1
AI-HPCC, AI-NANO-HPCC, 5 axis machining mode:
FRP(No.19501#5)=1
3. In case rapid traverse is executed with RISC board in the same way
as normal during HPCC mode (Parameter SG0(No.8403#7)=1,
STG(No.8404#0)=1 and HG0(No.8404#1)=1), the constant
acceleration time type Acc/Dec for rapid traverse (Parameter
LRP(No.1401#1)=1, PRT(No.1603#4)=1) cannot be selected.
4. In case Acc/dec rapid traverse is selected as Acc/Dec after
interpolation (Parameter FRP(No.19501#5)=0) during AI-HPCC, AI-
NANO-HPCC, 5 axis machining modes, the constant acceleration
time type Acc/Dec for rapid traverse (Parameter LRP(No.1401#1)=1,
PRT(No.1603#4)=1) cannot be selected.
1621
Time constant used for bell–shaped acceleration/deceleration (T2)
in rapid traverse for each axis
1774
Time constant used for bell–shaped acceleration/deceleration (T2)
in rapid traverse for each axis
during AICC, AI-NANO-CC, HPCC, AI-HPCC, AI-NANO-HPCC and
5-axis machining function modes
[Data type] Word axis
[Unit of data] msec
[Valid data range]
Function Data range
Normal operation
APC
0 ~ 512
Data range
Acc/Dec before
interpolation
Acc/Dec after
interpolation
Function
AIR(No.7054#1)=0
or
AIR(No.7054#1)=1 &
LRP(No.1401#1)=1
AIR(No.7054#1)=1 &
LRP(No.1401#1)=0
AI-APC 0 ~ 512
AICC 0 ~ 256
AI-NANO-CC
0 ~ 512
0 ~ 512 (*1)
