PWM Distribution Module, DESCRIPTIONS Additional Manual Page 5

Additional Manual
DRAW.
No.
TITLE
Pa
g
e
005
/
24
DESCRIPTIONDESIGNDATE EDIT
PWM Distribution Module
DESCRIPTIONS
Ａ-72562E-029
FANUC LTD
3. ORDAERING INFORMATON
3.1. PWM DISTRIBUTION MODULE (PDM)
Category Name Ordering number Remarks
Standard PWM DISTRIBUTON MODULE A06B-6135-H001 0.3kg
3.2. Connectors
Category Ordering
number
Manufacturer Part number Q’TY Remarks
FI40B-2015S
connector
1 Standard A06B-6078-K225 Hirose Electric
Co., Ltd.
FI-20-CVS2 case 1
For pulse
coder
IL-L2S-S3L-B(N)
housing
1
Optional A06B-6093-K303
Japan Aviation
Electronics Industry, Ltd
IL-C2-1-00001
contact
2
For
battery
3.3. Fuses
Category Ordering number Remarks
Standard
A06B-6073-K250
Manufacturer : Daito Communication
Apparatus Co.,Ltd
Specification : 3.2A / 48V
Use : For short-circuit protection of 24VDC power supply
3.4. Battery for absolute Pulsecoder
Category Name Ordering number Remarks
Built-in Battery A06B-6135-K001 Built-in PDM
Battery holder A06B-6135-K002 Built-in PDM
Battery A06B-6050-K061
Optional
Battery case A06B-6050-K060
4. SPECIFICATONS
Item Specification
Power supply capacity Voltage 24 VDC +/- 10%
Current 0.4A(max)
Ambient Temperature 0
o
C to 55
o
C
Method of installation A PDM can be installed by using screws or DIN rail.
5. HEAT DISSIPATION
6W
