FANUC Series 30i/31i/32i -MODEL A
Tool management function
magazine property/pot property
13510
Number of lines of the fifth magazine (when the magazine is of the matrix
type)
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Word type
[Valid data range] 1 to 1000
When the fifth magazine is of the matrix type (bit 4 (MT5) of parameter No.
13240 is set to 1), set the number of lines in the pot in this parameter. The
setting must satisfy the following condition, however: The sum total of the
value obtained by (setting of parameter No. 13510) (setting of parameter
No. 13511) and the number of pots of other magazines should not exceed 64
(1000 at maximum). If this condition is not satisfied or this parameter is set
to 0, the fifth magazine is invalid.
13511
Number of rows of the fifth magazine (when the magazine is of the matrix
type)
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Word type
[Valid data range] 1 to 1000
When the fifth magazine is of the matrix type (bit 4 (MT5) of parameter No.
13240 is set to 1), set the number of rows in the pot in this parameter. The
setting must satisfy the following condition, however: The sum total of the
value obtained by (setting of parameter No. 13510) (setting of parameter
No. 13511) and the number of pots of other magazines should not exceed 64
(1000 at maximum). If this condition is not satisfied or this parameter is set
to 0, the fifth magazine is invalid.
