FANUC Series 30i/31i/32i-MODEL A, Tool Management Function Magazine Property/Pot Property, Specification Supplement to Manual Page 19

Supplement to Manual
A-90234E
Title
Draw
No.
Ed. Date Design Description
Date Sep.26.’05 Design. Apprv.
19/19
page
FANUC Series 30i/31i/32i -MODEL A
Tool management function
magazine property/pot property
13516
Number of lines of the eighth magazine (when the magazine is of the matrix
type)
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Word type
[Valid data range] 1 to 1000
When the eighth magazine is of the matrix type (bit 7 (MT8) of parameter
No. 13240 is set to 1), set the number of lines in the pot in this parameter.
The setting must satisfy the following condition, however: The sum total of
the value obtained by (setting of parameter No. 13516) (setting of
parameter No. 13517) and the number of pots of other magazines should not
exceed 64 (1000 at maximum). If this condition is not satisfied or this
parameter is set to 0, the eighth magazine is invalid.
13517
Number of rows of the eighth magazine (when the magazine is of the matrix
type)
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Word type
[Valid data range] 1 to 1000
When the eighth magazine is of the matrix type (bit 7 (MT8) of parameter
No. 13240 is set to 1), set the number of rows in the pot in this parameter.
The setting must satisfy the following condition, however: The sum total of
the value obtained by (setting of parameter No. 13516) (setting of
parameter No. 13517) and the number of pots of other magazines should not
exceed 64 (1000 at maximum). If this condition is not satisfied or this
parameter is set to 0, the eighth magazine is invalid.
