FANUC Series 30i/31i/32i-MODEL A, Tool Management Function Magazine Property/Pot Property, Specification Supplement to Manual Page 7

Supplement to Manual
A-90234E
Title
Draw
No.
Ed. Date Design Description
Date Sep.26.’05 Design. Apprv.
7/7
page
FANUC Series 30i/31i/32i -MODEL A
Tool management function
magazine property/pot property
Input/output with external device
The following data can be inputted/outputted with the mentioned G10
format from/to external device.
- Magazine property
- pot property
- the number of decimal places for customize data in magazine property
- the number of decimal places for customize data in pot property
- the name of customize data in magazine property,
- the name of customize data in pot property
When the data is input/output without specifying file name, the data is
input/output by the following default file name
“MAG_PRTY.TXT” Magazine property
“POT_PRTY.TXT” Pot property
“MAG_CDEC.TXT” The number of decimal places for customize
data in pot property
“POT_CDEC.TXT” The number of decimal places for customize
data in pot property
“MAG_CNAM.TXT” The name of customize data in magazine
property,
“POT_CNAM.TXT” The name of customize data in pot property
