FANUC Series 30i/31i/32i -MODEL A
Tool management function
magazine property/pot property
<The number of decimal places in magazine property>
G10 L77 P10 ;
N_ R_;
G11;
N_ : Customize data number(1 to 4)
R_ : The number of decimal places(0 to 7)
<The number of decimal places in pot property>
G10 L77 P11 ;
N_ R_;
G11;
N_ : Customize data number(1 to 10)
R_ : The number of decimal places(0 to 7)
<The name of customize data in magazine property>
G10 L77 P12 ;
P_ R_;
P_ R_;
P_ R_;
G11;
P_ : Customize data number(1 to 4)
P_ : Character number(1 to 16)
R_ : Character code(ANK or Shift JIS)
<The name of customize data in pot property>
G10 L77 P13 ;
P_ R_;
P_ R_;
P_ R_;
G11;
P_ : Customize data number(1 to 10)
P_ : Character number(1 to 16)
R_ : Character code(ANK or Shift JIS)
