Series 0i Mate - TB Operators manual Page 627

Operators manual

Page of 756

/ 756

B-63854EN/03 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i

- 603 -

1.4.2.5 Machining type block of Groove roughing in turning

Outer Groove Roughing : G1130

End face Groove Roughing : G1132

Data item Comment

F FEED RATE Cutting feedrate

E TOOL WIDTH Width of grooving tool at cutting edge (radius)

Q CUTTING DEPTH Depth of each cutting motion (outer/inner : diameter,

end face : radius)

R DWELL TIME Dwell time at the bottom of grove, in unit of msec.

H FINISH AMOUNT X Finishing amount of X-axis direction (diameter)

K FINISH AMOUNT Z Finishing amount of Z-axis direction (radius)

W CUTTING METHOD Cutting sequence of groove part

1 : Single direction

Cutting is done from end face toward chuck side

2: Both direction

At first, cutting at the center of groove is done, and

expanded to end face side and chuck side mutually

J RATE OF CUTTING

DEPTH

Ratio of the depth of an actual cut to the depth of cut

entered by Q

U MINIMUM CUT DEPTH Limit of depth of cut (diameter)

1.4.2.6 Machining type block of Groove finishing in turning

Outer Groove Finishing : G1133

End face Groove Finishing : G1134

Data item Comment

F FEED RATE Cutting feedrate

E TOOL WIDTH Width of grooving tool at cutting edge (radius)

W CUTTING METHOD Cutting sequence of groove part

1 : Single direction

Cutting is done from end face toward chuck side

2: Both direction

At first, cutting at the center of groove is done, and

expanded to end face side and chuck side mutually
