B-63854EN/03 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i

- 633 -

(2) When specifying a line with two points

By pressing [XZ,XZ], you can specify a line with two passing

points.

By pressing [XZ, A], you can select the above type by using an

angle again.

Data item Comment

BASE POINT X X coordinate of the base point positioned apart from a

line

BASE POINT Z Z coordinate of the base point positioned apart from a

line

PASS POINT U X coordinate of the 1st passing point on the line

PASS POINT W Z coordinate of the 1st passing point on the line

PASS POINT P X coordinate of the 2nd passing point on the line

PASS POINT Q Z coordinate of the 2nd passing point on the line

SHIFT DIST. D When the line should be specified by shifting an original

line, enter the shifting distance

SHIFT DIRC. Select a shifting direction by arrow soft-keys

- Cross point between 2 lines

The cross point of two lines can be calculated. Furthermore, this

calculation can also be done for a line that is shifted from its original

position by some distance.

This can be useful when entering a tool path that is shifted from the

original figure by an amount equal to the tool radius.

(a) When specifying a line with one point and an angle

Initially, the following data items are displayed for Line-1.

Data item Comment

PASS POINT X X coordinate of a certain point on the line

BASE POINT Z Z coordinate of a certain point on the line

ANGLE A Angle of line from +Z-axis. A positive angle is counter

clockwise direction.

SHIFT DIST. D When the line should be specified by shifting an original

line, enter the shifting

Distance

SHIFT DIRC. Select a shifting direction by arrow soft-keys

By pressing [NEXT] after entering the necessary data, a similar

data item screen for Line-2 is displayed. By pressing [PREV.],

you can return to the previous screen for Line-1.

(b) When specifying a line with two points

By pressing [XZ,XZ], you can specify a line with two passing

points.

By pressing [XZ, A], you can select the above type by using an

angle again.

The following data items are displayed respectively for Line-1

and Line-2.

Data item Comment

PASS POINT X X coordinate of the 1st passing point on the line

PASS POINT Z Z coordinate of the 1st passing point on the line

PASS POINT U X coordinate of the 2nd passing point on the line
