G. ALARM LIST

701

Number ContentsMessage

5228 SAME NAME USED There are duplicate file names in the built–in Handy File.

5229 WRITE PROTECTED A floppy disk in the built–in Handy File is write protected.

5231 TOO MANY FILES The number of files exceeds the limit during communication with the

built–in Handy File.

5232 DATA OVER–FLOW There is not enough floppy disk space in the built–in Handy File.

5235 COMMUNICATION ERROR A communication error occurred during communication with the built–in

Handy File.

5237 READ ERROR A floppy disk in the built–in Handy File cannot be read from. The floppy

disk may be defective, or the head may be dirty. Alternatively, the Handy

File is defective.

5238 WRITE ERROR A floppy disk in the built–in Handy File cannot be written to. The floppy

disk may be defective, or the head may be dirty. Alternatively, the Handy

File is defective.

5257 G41/G42 NOT ALLOWED IN MDI

MODE

G41/G42 (cutter compensation C: M series, tool–nose radius com-

pensation: T series) was specified in MDI mode. (Depending on the set-

ting of bit 4 of parameter No. 5008)

5303 TOUCH PANEL ERROR A touch panel error occurred.

Cause:

1. The touch panel is kept pressed.

2. The touch panel was pressed when power was turned on.

Remove the above causes, and turn on the power again.

5306 MODE CHANGE ERROR In an one–touch macro call, the mode is not normally switched at the

beginning.

5311 FSSB : ILLEGAL CONNECTION 1. This alarm is issued if, in a pair of axes in which one axis has an

odd servo axis number (parameter No. 1023) and the other has an

even servo axis number that is adjacent to the odd servo axis

number, one of the axes is assigned to an amplifier connected to

an FSSB in a system different from that for the other axis.

2. This alarm is issued if the system does not satisfy a constraint for

performing high–speed HRV control, current control periods for

two FSSBs are different, and it is specified that pulse modules

connected to an FSSB in different paths are to be used.

2) Background edit alarm

Number Message Contents

070 to 074

085 to 087

BP/S alarm BP/S alarm occurs in the same number as the P/S alarm that occurs in

ordinary program edit.

140 BP/S alarm It was attempted to select or delete in the background a program being

selected in the foreground. (Note)

Use background editing correctly.

NOTE

Alarm in background edit is displayed in the key input line of the background edit screen instead

of the ordinary alarm screen and is resettable by any of the MDI key operation.

3) Absolute pulse coder (APC) alarm

Number Message Contents

300 n AXIS NEED ZRN Manual reference position return is required for the nth–axis (n=1 – 4).

301 APC ALARM:n AXIS

COMMUNICATION

nth–axis (n=1 – 2) APC communication error. Failure in data transmission

Possible causes include a faulty APC, cable, or servo interface module.
