1.5.1.5 Convert to NC Program

Entered contour figures can be converted to NC programs in the form

of G-code.

Press [NC CNV]. The following screen appears.

By following the message displayed on the screen, press [YES]

immediately or press it after entering a sub program number.

If you press [YES] without entering a sub program number, the

contour figures will be entered immediately after the cursor before the

start of Contour programming.

If you press [YES] after entering a new sub program number, the

contour figure will be entered into the newly made sub program, and a

sub-program calling block such as M98 Pxxxx will be entered

immediately after the cursor before the start of Contour programming.

By pressing [NO], you can abandon the conversion operation.

Contour figures can be converted to the following G-code programs.

G-code

Type of Figure Symbol

Normal ISO-code program

Figure block for Stock

removal cycle

Start point

G00 or G01 G1400

Line → G01 G1401

Arc (CW) G02 G1402

Arc (CCW) G03 G1403

Corner R R G02 or G03 G1402 or G1403

Chamfering C G01 G1401

Cutter compensation G41 or G42 None

Cutter compensation

cancel

G40 None

CONFIRM CONVERSION OF NC PROGRAM

YOU CAN SELECT NC CONVERSION TYPE

PUSH [YES] WITH NO DATA INPUT

→ NC PROGRAM WILL BE ENTERED TO ACTUAL PROGRAM

ENTER SUB PROGRAM NUMBER, THEN PUSH [YES]

→ NC PROGRAM WILL BE ENTERED AS A SUB PROGRAM

[YES][NO][ ][ ][ ]
