APPENDIX

B–63854EN/03

C. RANGE OF COMMAND VALUE

679

Increment system

Least input increment 0.0001 inch

Least command increment X : 0.00005 inch

(diameter specification)

Y : 0.0001 inch

(radius specification)

Max. programmable

dimension

±9999.9999 inch

Max. rapid traverse *1 9600 inch/min

Feedrate range *1 Feed per minute :

0.01 to 9600 inch/min

Feed per revolution

0.000001 to 9.999999 inch/rev

Incremental feed 0.0001, 0.001, 0.01, 0.1 inch/step

Tool compensation 0 to ±99.9999 inch

Dwell time 0 to 99999.999 sec

Increment system

Least input increment 0.001 mm

Least command increment X : 0.00005 inch

(diameter specification)

Y : 0.0001 inch

(radius specification)

Max. programmable

dimension

±99999.999 mm

Max. rapid traverse *1 9600 inch/min

Feedrate range *1 Feed per minute :

1 to 240000 mm/min

Feed per revolution

0.0001 to 500.0000 mm/rev

Incremental feed 0.001, 0.01, 0.1, 1mm/step

Tool compensation 0 to ±999.999 mm

Dwell time 0 to 99999.999 sec

D In case of inch

input, feed screw is

inch

D In case of millimeter

input, feed screw is

inch
