FANUC Series 30i-MODEL A
Index Table Indexing
Parameter
- Setting linear or rotation axis
#7 #6 #5 #4 #3 #2 #1 #0
1006 ROSx ROTx
[Data type] Bit axis
ROTx, ROSx Setting linear or rotation axis.
ROSx ROTx Meaning
0 0 Linear axis
(1) Inch/metric conversion is done.
(2) All coordinate values are linear axis type. (Is not rounded
in 0 to 360
°)
(3) Stored pitch error compensation is linear axis type (Refer
to parameter No.3624)
0 1 Rotation axis (A type)
(1) Inch/metric conversion is not done.
(2) Machine coordinate values are rounded in 0 to 360
°.
Absolute coordinate values are rounded or not rounded
by parameter No.1008#0(ROAx) and #2(RRLx).
(3) Stored pitch error compensation is the rotation type.
(Refer to parameter No.3624)
(4) Automatic reference position return (G28, G30) is done in
the reference position return direction and the move
amount does not exceed one rotation.
1 0 Setting is invalid (unused)
1 1 Rotation axis (B type)
(1) Inch/metric conversion, absolute coordinate values and
relative coordinate values are not done.
(2) Machine coordinate values, absolute coordinate values
and relative coordinate values are linear axis type. (Is not
rounded in 0 to 360
°).
(3) Stored pitch error compensation is linear axis type (Refer
to parameter No.3624)
(4) Cannot be used with the rotation axis roll over function
and the index table indexing function (M series)
