FANUC Series 30i-MODEL A
Index Table Indexing
Caution
CAUTION
1 While the index table is being positioned, input
signals that reset the CNC, such as emergency
stop, feed hold, and interlock are functional.
If a stop at an any position is not suitable for the
machine, appropriate processing is required on the
machine.
2 If the axis selection signal is set to 0 during manual
reference position return, movement is stopped
immediately, and the clamp command is not
executed. If this proves inconvenient, measures
must be taken on the machine side so that, after
the axis selection signal is set to 1, it is not set to 0
until reference position return is completed.
3 When an incremental command is used for
indexing the index table (when bit 3 (G90) of
parameter No. 7602 is 0), the workpiece origin
offset for the index table axis must always be 0.
This means that the workpiece coordinate system
and machine coordinate system of the index table
axis must always match.
4 If a reset is made during indexing of the index
table, a reference position return must be made
before the index table is indexed subsequently.
5 The secondary auxiliary function can be used, but
its address must be different from that of the
indexing axis.
Note
NOTE
1 For positioning on an index table indexing axis, the
dry run signal DRN has no effect.
2 This function is optional.
Previous page
Next page

Contents Summary of Series 30i-MODEL A, Index Table Indexing Additional Manual

  • Page 1TECHNICAL REPORT NO. TMN 04/020E Date :Mar .30, 2004 General Manager of Software Laboratory FANUC Series 30i-A Newly additional functions 1. Communicate this report to: Your information only GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON Machine tool builder Sales agency End user 2. Summary for Sale
  • Page 2FANUC Series30i –A newly additional functions Drawing number Functions 1 A-79227E External Data Input 2 A-79226E One Touch Macro call 3 A-79196E Temporary absolute coordinate setting 4 A-79354E System alarm 5 A-79349E Touch Panel Control 6 A-79253E Distance coded linear scale interface 7 A-79364E Li
  • Page 3FANUC Series 30i-MODEL A Index Table Indexing SPECIFICATIONS FANUC Series 30i-MODEL A Title Index Table Indexing Draw A-79355E No. Ed. Date Design Description Sheet 1/12 Date Jan.06.’04 Desig. Apprv.
  • Page 41.1 INDEX TABLE INDEXING (M SERIES) General By specifying indexing positions (angles) for the indexing axis (one rotation axis, A, B, or C), the index table of the machining center can be indexed. Before and after indexing, the index table is automatically unclamped or clamped. Explanation - Basic P
  • Page 5This completes the sequence. The time charts for these operations are shown in the figures below. (1) (2) (3) (4) (5) (6) (7) (8) (9) B command (independent) B axis servo on for position control B axis unclamp signal BUCLP B axis unclamp completion signal *BEUCL B axis rotation B axis clamp signal B
  • Page 6The figure below shows the timing chart for type-A manual reference position return of the B axis. B axis manual feed selection signal +Jα B axis position control servo ON B axis unclamp signal BUCLP B axis unclamp completion signal *BEUCL B axis rotation B axis deceleration signal *DECα B axis retu
  • Page 7If 0 is set in the M code for specifying negative direction rotation (parameter No.5511), the rotation direction in G90 mode is determined by bit 3 (INC) of parameter No.5500, as described below. The rotation direction in G90 mode is 0: Not shortcut direction 1: Shortcut direction (The amount of mov
  • Page 8Limitation - Simultaneous specification together with other controlled axes Operation performed when the same block specifies an index table indexing command and another control axis depends on the setting of bit 1 (SIM) of parameter No. 5500 as follows: ･ SIM = 0 An index table indexing command is
  • Page 9Signal B axis clamp signal *BCLP [Classification] Output signal [Function] Instructs the PMC side to clamp the B axis mechanically with a clutch or shot pin. [Output condition] The output condition and procedure are the same as those described in the basic procedure for positioning the index
  • Page 10Parameter - Setting linear or rotation axis #7 #6 #5 #4 #3 #2 #1 #0 1006 ROSx ROTx [Data type] Bit axis ROTx, ROSx Setting linear or rotation axis. ROSx ROTx Meaning 0 0 Linear axis (1) Inch/metric conversion is done. (2) All coordinate values are linear axis type. (Is not rounded in 0 to 360°) (3)
  • Page 11- Setting for positioning the index table #7 #6 #5 #4 #3 #2 #1 #0 5500 IDX SIM G90 INC ABS REL DDP [Data type] Bit path #0 DDP Selection of a decimal point input method for an index table indexing axis 0 : Conventional method (Example IS-B: B1; = 0.001 deg) 1 : Calculator method (Example IS-B: B1; =
  • Page 12#7 #6 #5 #4 #3 #2 #1 #0 5501 ISP ITI [Data type] Bit path #0 ITI Index table indexing function is : 0 : Enabled. 1 : Disabled. #1 ISP Upon completion of clamping, index axis servo-off operation is: 0 : Processed by the CNC. 1 : Not processed by the CNC. (The state of the servo-off signal (G0126) inp
  • Page 13- Setting of a minimum positioning angle for index table indexing 5512 Minimum positioning angle for index table indexing [Data type] Real path [Unit of data] Degree [Minimum unit of data] Depend on the increment system of the applied axis [Valid data range] 0 or positive 9 digit of minimum unit of
  • Page 14Caution CAUTION 1 While the index table is being positioned, input signals that reset the CNC, such as emergency stop, feed hold, and interlock are functional. If a stop at an any position is not suitable for the machine, appropriate processing is required on the machine. 2 If the axis selection sig
