FANUC Series 30i-MODEL A
Index Table Indexing
Signal
B axis clamp signal *BCLP<F061#1>
[Classification] Output signal
[Function] Instructs the PMC side to clamp the B axis mechanically with a clutch or
shot pin.
[Output condition] The output condition and procedure are the same as those described in the
basic procedure for positioning the index table.
B axis clamp completion signal *BECLP<G038#7>
[Classification] Input signal
[Function] Notifies the CNC of completion of the B axis clamp operation.
[Operation] The output condition and procedure are the same as those described in the
basic procedure for positioning the index table.
B axis unclamp signal *BUCLP<F061#0>
[Classification] Output signal
[Function] Instructs the PMC side to release the B axis from the mechanical clamp.
[Output condition] The output condition and procedure are the same as those described in the
basic procedure for positioning the index table.
B axis unclamp completion signal *BEUCL<G038#6>
[Classification] Input signal
[Function] Notifies the CNC of completion of the release of the B axis from the
mechanical clamp.
[Operation] The output condition and procedure are the same as those described in the
basic procedure for positioning the index table.
Signal address
#7 #6 #5 #4 #3 #2 #1 #0
Gn038 *BECLP *BEUCL
#7 #6 #5 #4 #3 #2 #1 #0
Fn061 BCLP BUCLP
