FANUC Series 30i-MODEL A
Index Table Indexing
- Setting of a minimum positioning angle for index table indexing
5512 Minimum positioning angle for index table indexing
[Data type] Real path
[Unit of data] Degree
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard parameter
setting table (A))
(When the increment system is IS-B, -999999.999 to +999999.999)
Set a minimum positioning angle (travel distance) on an index table indexing
axis. A travel distance specified with a positioning command must be an
integral multiple of the setting of this parameter. When 0 is specified, no
travel distance check is made.
A minimum positioning angle check is made with not only commands but
also a coordinate system setting and workpiece origin offset.
Alarm
Number Message Contents
PS1508 DUPLICATE M-CODE (INDEX TABLE
REVERSING)
The same code as this M code is set in a function.
(Index table indexing)
PS1561 ILLEGAL INDEXING ANGLE The specified angle of rotation is not an integer multiple of
the minimum indexing angle.
PS1564 INDEX TABLE AXIS – OTHER AXIS
SAME TIME
The index table indexing axis and another axis have been
specified in the same block.
PS1567 INDEX TABLE AXIS DUPLICATE
AXIS COMMAND
Index table indexing was specified during axis movement
or on an axis for which the index table indexing sequence
was not completed.
Previous page
Next page
