Series 30i-MODEL A, Index Table Indexing Additional Manual Page 12

Additional Manual
A-79355E
Title
Draw
No.
Ed. Date Design Description
Date Jan.06.’04 Desig. Apprv.
10/12
Sheet
FANUC Series 30i-MODEL A
Index Table Indexing
#7 #6 #5 #4 #3 #2 #1 #0
5501 ISP ITI
[Data type] Bit path
#0 ITI Index table indexing function is :
0 : Enabled.
1 : Disabled.
#1 ISP Upon completion of clamping, index axis servo-off operation is:
0 : Processed by the CNC.
1 : Not processed by the CNC. (The state of the servo-off signal (G0126)
input from the PMC is followed.)
- Setting of an index table indexing axis
5510 Control axis number for an index table indexing axis
[Data type] Byte path
[Valid data range] 0 to number of controlled axes
Set a control axis number for an index table indexing axis.
When 0 is set, the specification of the fourth axis is assumed.
- Negative direction rotation command M code
5511 Negative direction rotation command M code
[Data type] 2-word
[Valid data range] 0 to 99999999
0 : No M code is defined to set the index table rotation to the negative
direction. The rotation direction is specified using a command and
parameter (INC, #3 of parameter No. 5500).
1 to 99999999 :
A movement on an index table indexing axis is made in the positive
direction at all times. A movement in the negative direction is made
only when an M code set together with a move command is specified.
NOTE
Set ABS (bit 2 of parameter No. 5500) to 1.
