Descriptions
B-65332EN/01 PREFACE
p-3
1.2 ACCEPTANCE AND STORAGE
WARNING
Mishandling a rotor may be highly dangerous,
resulting in a fatal accident. Read and thoroughly
understand the cautions on the next page and Part
III, "HANDLING, DESIGN, and INSTALLATION,"
before handling the rotor and strictly observe the
cautions when handling it. Do not handle the rotor
unless you have been trained in handling
synchronous built-in servo motors.
A "motor" described in this manual means all parts
of the synchronous built-in servo motor: Stator,
rotor, and others.
After you have received a FANUC SYNCHRONOUS BUILT-IN
ERVO MOTOR, check it as follows: S
• Is the motor exactly what you ordered? Check the motor model.
• Is it free from any damage? Damage may have occurred during
shipment.
• Are all accessories supplied with the motor?
All models of stators are supplied with a nameplate and
laminate sheet.
All FANUC SYNCHRONOUS BUILT-IN SERVO MOTORs are
strictly inspected and carefully packed before shipment. They need no
special incoming inspection. Just check the specifications (for wiring,
current, voltage, and other data) of the motor as required. When
measuring resistance and insulation data, reference Part V,
"MAINTENANCE." Be extremely careful in measuring the
dimensions of the rotor as incoming inspection because it has very
trong magnetism. s
• Do not apply unnecessary external force or shock to the motor.
Otherwise, the motor may be damaged and become incapable of
operating normally.
• Do not machine the motor without permission. If the motor
requires machining, machine only the portion specified or
approved by FANUC.
• Keep the motor from contact with and away from water and oil,
chemicals which may damage motors, conductive materials, and
other materials harmful to motors.
• Store the motor in indoor locations where are free from rainwater,
condensation, and excessive dust. Avoid warming or cooling the
motor externally when unnecessary and placing it in special
environments.
