SYNCHRONOUS BUILT-IN SERVO MOTOR Dis series Descriptions Page 16

Descriptions
B-65332EN/01 PREFACE
p-5
failure of an item due to magnetic fields.
media
resulting in injury. If your hand is caught under the
tor, it is difficult even to pull out the hand. Be extremely careful in
m
FANUC accepts no liability for any damage such as corruption or
• Watches, cellular phones, magnetic cards, and other portable
items
• Magnetic tapes, floppy disks, MO disks, and other magnetic
• Cameras, personal computers, and other electronic devices
When moving the rotor on a surface of a magnetic material such as the
mounting surface of the machine or a table, always place it flat with
the mounting side facing up and slide it. If the rotor is moved with
rotating it on its magnet surface, the rotor may be attracted to the
magnetic material and your hand may be caught between the rotor and
magnetic material,
ro
oving the rotor.
