SYNCHRONOUS BUILT-IN SERVO MOTOR Dis series Descriptions Page 20

Descriptions
1.OVERVIEW SPECIFICATIONS B-65332EN/01
- 4 -
FANUC does not supply parts other than listed above. Use parts
manufactured by 3rd parties as required.
NOTE
1 Select a rotary encoder which meets the FANUC
specifications. For details, see Part II,
"CONFIGURATIONS AND SELECTION."
2 FANUC does not currently supply any system
consisting of a synchronous built-in servo motor,
bearing, rotary encoder, and other parts you can
use as a machine immediately after you purchase
it. As described above, you must purchase required
parts and configure a system. When you use a
motor consisting of parts supplied by FANUC under
the specified conditions, FANUC guarantees the
performance of the motor. For a part which is not
supplied by FANUC, its performance is guaranteed
by the relevant manufacturer. For details of a part
which is not supplied by FANUC, contact the
relevant parts manufacturer or dealer.
Previous page
Next page
