D OPTICAL FIBER CABLE

The 30i series uses optical fiber cables for the following interfaces.

This table lists the usable combinations.

Interface Junction

Recommended

optical cable

Maximum

allowable

transmission

distance

Junction adapter

none A66L-6001-0026#L~ 100m

Serial spindle interface

exist A66L-6001-0029#L~ 55m *2 A63L-0020-0004

none A66L-6001-0026#L~ 200m

I/O Link interface

exist A66L-6001-0026#L~ 100m *2 A63L-0020-0002

none A66L-6001-0023#L~ 10m

none A66L-6001-0026#L~ 50m

High speed serial bus

(HSSB)

interface

Between stand-alone

control unit and LCD

exist A66L-6001-0029#L~ 35m

*2 A63L-0020-0004

none A66L-6001-0023#L~ 10m

Serial servo bus (FSSB)

interface

none A66L-6001-0026#L~ 50m

*Note)

1. When an optical fiber cable is used for connection.

2. Only one relay point is permitted. And you can relay two optical fiber cables

on condition that the sum of the line length of two cables is within the range of the

maximum allowable transmission distance or less.

3. Obey the following cable length restriction about the FSSB 1 line.

• 50m or less between CNC and the first slave unit

• 40m or less between each slave units

• The total line length that adds the above-mentioned is 500m or less.
