FANUC High Speed Serial Bus for 30i Series Additional Manual Page 11

Additional Manual
EDIT
SHEE
DRAW. NO. CUST.
TITLE
DESCRIPTION DESIG.DATE
FANUC HIGH SPEED SERIAL BUS FOR
30i SERIES CONNECTING AND
MAINTENANCE MANUAL
A
-85114E
11
/
24
5. Mounting Method of Interface Board for Personal Computer
(1) Mounting Method
Never touch the card edge terminals (contacts with card).
1. Remove the covering plate of the personal computer.
2. Insert the interface board for the personal computer to the PCI slot tightly.
3. Screw the plate of interface board to the computer.
4. Confirm connection (in case that multiple HSSB interface boards are exist)
Confirm following items for installing drivers of HSSB interface board.
- PCI slot number which HSSB board is mounted (slot number is marked to PCB normally).
- Correspondence between HSSB channel and CNC
5. Restore the covering plate.
