FANUC High Speed Serial Bus for 30i Series Additional Manual Page 6

Additional Manual
EDIT
SHEE
DRAW. NO. CUST.
TITLE
DESCRIPTION DESIG.DATE
FANUC HIGH SPEED SERIAL BUS FOR
30i SERIES CONNECTING AND
MAINTENANCE MANUAL
A
-85114E
6
/
24
(2) Usable Optical Fiber Cables
Name Number (
xxxxx is length) Maximum Length Remark
Optical Fiver Cable B A66L-6001-0026#Lxxxxx
*3
50m FSSB external cable
Optical Fiver Cable C A66L-6001-0029#Lxxxxx
*4
35m
*2
Low-loss junction only
cable
*2: If a junction adapter is used,
- Junction point should be one.
- Optical Fiber Cable C must be used as each cable.
- Specification of junction adapter is A63L-0020-0004.
*3: List of Optical Fiber Cable B
A66L-6001-0026#L1R003 : Cable Length = 1m
A66L-6001-0026#L3R003 : Cable Length = 3m
A66L-6001-0026#L5R003 : Cable Length = 5m
A66L-6001-0026#L7R003 : Cable Length = 7m
A66L-6001-0026#L10R03 : Cable Length = 10m
A66L-6001-0026#L15R03 : Cable Length = 15m
A66L-6001-0026#L20R03 : Cable Length = 20m
A66L-6001-0026#L30R03 : Cable Length = 30m
A66L-6001-0026#L40R03 : Cable Length = 40m
A66L-6001-0026#L50R03 : Cable Length = 50m
*4: List of Optical Fiber Cable C
A66L-6001-0029#L1R003 : Cable Length = 1m
A66L-6001-0029#L3R003 : Cable Length = 3m
A66L-6001-0029#L5R003 : Cable Length = 5m
A66L-6001-0029#L7R003 : Cable Length = 7m
A66L-6001-0029#L10R03 : Cable Length = 10m
A66L-6001-0029#L15R03 : Cable Length = 15m
A66L-6001-0029#L20R03 : Cable Length = 20m
A66L-6001-0029#L30R03 : Cable Length = 30m
Optical fiber cable must not be cut or joined by customer. Please buy the cable with the necessary
length from FANUC or the cable vender authorized by FANUC.
