3. Specification and Environment
(1) Specification of Interface Board for Personal Computer
• FANUC requires the customer to buy and maintain the personal computer itself.
• FANUC is not responsible for proper working about personal computer itself and any troubles
caused by using personal computer.
・ This interface board for the personal computer is based on the PCI specifications and it can be used into a
computer with PCI slot (5V,32bit, and Rev.2.1 or later).
・ Please examine proper working sufficiently about communication between the personal computer and CNC
controller
・ Suspend mode is not supported.
・ This board requires following power supply.
Specification Order Number Power Supply
A20B-8101-0163 +5V 1A
1ch Board A20B-8101-0161
*5
+5V, 1A
+12V 20mA
A20B-8101-0162 +5V 1.5A
2ch Board A20B-8101-0160
*5
+5V, 1.5A
+12V 20mA
*5: Please order -0163 or -0162 from now on.
-0160 can be swapped for -0162, -0161 can be swapped for -0163.
(2) Envionment of Interface Board for Personal Computer
Operating
0～55 C
Ambient
Temperature
Non-operating
-20～60C
Usual
10～75% (non-condensing)
Humidity
Short-term(within one month)
10～95% (non-condensing)
Please keep above environmental requirement and environmental requirement for personal computer.
(3) Envionment of PANEL i
Please strictly keep environmental requirement for PANEL i.
(4) Envionment for CNC unit and Interface Board for CNC
Please strictly keep environmental requirement for each CNC controller in which the interface board is
installed.
