FANUC Series 30i/31i Specifications of Auxiliary Function Table with Delay Time Additional Manual Page 11

Additional Manual
A-79969E
(2
5. Alarms
Alarm
No
Message Meanings
PS0451 ILLEGAL AUXILIARY
FUNCTION TABLE COMMAND
When M code is output, the ladder of the PMC does
not execute the completion processing of the previous
M code.
PS0452 ILLEGAL PATH TABLE
OPERATION
In Path Table operation, the following problems
occurred.
Skip command is not correct.
The connection of the Path Table is not correct.
Other Path Table operation is not correct.
The detail alarm number 55:
Delay time command of Auxiliary function cannot be
executed.
(2
Sheet
Title
Draw
No.
02 Oct. 22.'05 Addition or Modification of (2.
Ed. Date Design Description
Date Jan.31.’05 Desig. T.Watanabe Apprv. Y.Takeuchi
FANUC Series 30i/31i
Specifications of
Auxiliary function table with delay time
FANUC LTD
11/12
