FANUC Series 30i/31i Specifications of Auxiliary Function Table with Delay Time Additional Manual Page 5

Additional Manual
A-79969E
FOCAS2 window function
cnc_rdptcnvalm()
The conversion alarm number can be read with FOCAS2 window function
cnc_rdptcnvalm().
alm_no [ out ]
Conversion
Alarm No.
Meaning
323
The value of delay time is invalid.
324
Delay time is commanded in the spindle position reference table or
axis table.
325
Delay time is invalid.
(2
Sheet
Title
Draw
No.
02 Oct. 22.'05 Addition or Modification of (2.
Ed. Date Design Description
Date Jan.31.’05 Desig. T.Watanabe Apprv. Y.Takeuchi
FANUC Series 30i/31i
Specifications of
Auxiliary function table with delay time
FANUC LTD
5/12
