FANUC Series 30i/31i Specifications of Auxiliary Function Table with Delay Time Additional Manual Page 12

Additional Manual
A-79969E
6. Note
(2
Multiple M commands in a single block
If multiple M commands in a single block is used when parameter
M3B(No.3404#7) is set to "1", FANUC recommends that parameter
MHI(No.3001#7) should to be set to "1" and you use the high-speed M/S/T/B
interface.
Feedhold
If a feed hold stop is made when PTDLY signal<Fn531#0> is "1", PTDLY
signal<Fn531#0> is kept to be "1".
M code group check
M code group check is not available.
Parts count
When M code set in parameter No.6710 is specified as the first M-code,
parameter No.6711 that indicates parts count is incremented.
An optional function of display of run time and parts count is necessary.
Sheet
Title
Draw
No.
02 Oct. 22.'05 Addition or Modification of (2.
Ed. Date Design Description
Date Jan.31.’05 Desig. T.Watanabe Apprv. Y.Takeuchi
FANUC Series 30i/31i
Specifications of
Auxiliary function table with delay time
FANUC LTD
12/12
