FANUC Series 30i/31i Specifications of Auxiliary Function Table with Delay Time Additional Manual Page 7

Additional Manual
A-79969E
to effective, when the M code becomes effective at the certain table time, set
how much to output early from the table time which wants to be made
effective.
Example 2)
When the data table is as follows.
Time M code Delay time
800 [msec] 128 8 [msec]
When the override is changed, the M code output time (real time) is as follows.
A B
Override
%
Output
table time
[msec]
Output
real time
[msec]
Real time
for M code effect
[msec]
B - A
[msec]
100 792.0 792 800.0 8.0
90 792.0 880 888.9 8.9
80 793.6 992 1000.0 8.0
70 789.6 1128 1142.9 14.9
60 792.0 1320 1333.3 13.3
50 796.6 1592 1600.0 8.0
40 796.8 1992 2000.0 8.0
30 796.8 2656 2666.7 10.7
20 798.4 3992 4000.0 8.0
10 799.2 7992 8000.0 8.0
0 --------- ----------- --------------- ---------
Sheet
Title
Draw
No.
02 Oct. 22.'05 Addition or Modification of (2.
Ed. Date Design Description
Date Jan.31.’05 Desig. T.Watanabe Apprv. Y.Takeuchi
FANUC Series 30i/31i
Specifications of
Auxiliary function table with delay time
FANUC LTD
7/12
